Tehniline informatsioon: Application:
Screw connections on commercial vehicles and passenger cars
with XZN profile
e.g. on chassis, brake system (brake carriers), engines,
shock absorbers and camshaft sprocket
Installation and removal of the wheel bearing/hub unit
e.g. VW Touran, model year 2004 →, AUDI A3, model year 2004
→, Golf 5 as well as identical ŠKODA
Choice of Inside square (Robertson) drive 12.5 = 1/2″ or
Outside hexagon 24 mm
Short design
With borehole for locking pin or safety spring and grove
for O-ring
Surface: phosphatized, oiled
DIN 3124, ISO 2725-2
Made in Germany
Drive: Square, hollow 12.5 mm (1/2 inch), Outside hexagon
24 mm
Output: Internal serration profile XZN
Wrench size: M18
Dimensions / length: 43 mm
Length l1: 6 mm
Net weight: 0.1 kg
